Who invented the elevator?

By: Shanna Freeman  |
The next time you're playing the waiting game, consider how the elevator came to be.
Keith Brofsky/Photodisc/Thinkstock

Key Takeaways

  • Elisha Otis revolutionized elevator safety in 1852 with his design that included a safety brake.
  • Otis Tufts is sometimes credited with inventing the modern passenger elevator, due to his 1852 patent for an enclosed elevator with automatic door. But his design, which replaced ropes with a screw mechanism, was impractical and not widely adopted.
  • The Otis Elevator Company, founded by Elisha Otis, has become the world's largest manufacturer of elevators and escalators.

While you're zoning out in an elevator, waiting to reach your floor, do you ever wonder who came up with the idea? Probably not. We just expect to have safe, working elevators in multistory buildings -- and we get pretty irritated when we have to take the stairs instead. While there is one person typically credited with the invention, it's naturally more complicated than that.

Elevators existed as far back as ancient Rome; Archimedes was building them in 336 B.C., and gladiators and animals rode lifts to the Roman Coliseum arena by A.D. 80. Of course, those early "elevators" weren't enclosed cars. They were simple platforms and hoists, typically used to perform tasks such as raising up water for irrigation or lifting heavy building materials such as stones. These lifts were powered by animals, people or even water wheels.

Advertisement

What we're really talking about is the modern passenger elevator. The first one was built for King Louis XV in 1743 and was called "The Flying Chair." Installed on the outside of the king's palace at Versailles, his elevator went from the first to the second floor (linking the king's apartment to that of his mistress).The king entered it from his balcony, and then men stationed inside a chimney raised and lowered the elevator through the use of ropes and pulleys.

Elevators became more common in the mid-1800s during the Industrial Revolution when they transported freight in factories and mines. These elevators were often based on the hydraulic system. A piston inside a cylinder used pressure from water or oil to raise and lower the car. The drawback was that buildings with hydraulic elevators needed to have pits below the elevator shaft so that the piston could draw completely back. The higher the building was, the deeper the pit had to be. This design was impractical for very tall buildings, although it became popular in mansions because it could operate off the public water system.

Another elevator design (and the one found most often today in passenger elevators) uses a cable system, in which ropes raise and lower the car by means of a pulley and gear system. A counterweight, raised and lowered at the same time as the car, works like a seesaw and helps to conserve energy. These types of elevators are easier to control, and buildings that have them don't need the extra room required by hydraulic systems.

By the 1850s, these types of elevators were powered by water pressure or steam, but they still weren't very common. Read on to find out why -- and how the person who solved the problem may or may not be considered the inventor of the elevator.

Advertisement

Elisha Otis and Otis Tufts

At the time, elevators that operated on a cable system were considered unreliable and dangerous, because, if the ropes broke, the elevator plummeted to the bottom. Freight could be damaged, but, more importantly, passengers were often killed by the fall. The person who found a solution to this problem revolutionized the concept of the elevator. But was it Elisha Otis, or Otis Tufts?

While working in a factory in 1852, Elisha Otis and his sons came up with an elevator design that employed a safety device. A wooden frame at the top of the platform would snap out against the sides of the elevator shaft if the ropes broke, essentially functioning as a brake. Otis called it the "safety hoist" and dramatically demonstrated this design at the 1854 New York World's Fair. He rode the platform high into the air and then had the rope cut, but, thanks to the brake, it only fell a few inches before stopping. Otis founded an elevator company, Otis Brothers, which installed the first public elevator in a five-story New York department store in 1874. Electric elevators came about in the 1880s.

Advertisement

This means that Elisha Otis is the inventor of the modern passenger elevator, right? It depends on who you ask. Until the World's Fair demonstration, Otis hadn't had much luck selling elevators, and his initial elevator patent in 1861 was for a freight elevator -- the open platform kind -- not an enclosed passenger one. For this reason, some think of another Otis, Otis Tufts, as the actual inventor of the modern passenger elevator. Two years before Elisha Otis, Tufts patented an elevator design that had benches inside an enclosed car, with doors that opened and closed automatically.

There's a key reason why Elisha Otis gets the credit and not Tufts. Tufts' design did away with the typical rope and pulley system due to safety concerns. Instead, he used the concept of a nut threading up and down a screw. The elevator car was the nut, threaded onto a giant steel screw that extended the entire length of the shaft. While it was very safe, it was also expensive and impractical -- especially for very tall buildings. Tufts did sell a few of his elevators, but his design wasn't widely adopted.

The Otis Brothers Company (today known as the Otis Elevator Company) continued to make improvements in elevator safety and efficiency. Today, it's the world's largest manufacturer of elevators and escalators, while Tufts is known more for his inventions of the steam-powered printing press and the steam-powered pile driver.

Advertisement

Frequently Asked Questions

How did elevators impact urban development?
Elevators allowed for the construction of skyscrapers and the vertical expansion of cities, enabling the dense, high-rise environments we see in cities today.
What safety features are standard in modern elevators?
Modern elevators include multiple safety systems such as automatic braking, speed regulating systems and emergency alarms to ensure passenger safety.
