How Rail Guns Work

A rail gun is basically a large electric circuit, made up of three parts: a power source, a pair of parallel rails and a moving armature. Let's look at each of these parts in more detail.

The power supply is simply a source of electric current. Typically, the current used in medium- to large-caliber rail guns is in the millions of amps.

The rails are lengths of conductive metal, such as copper. They can range from four to 30 feet (9 meters) long.

The armature bridges the gap between the rails. It can be a solid piece of conductive metal or a conductive sabot -- a carrier that houses a dart or other projectile. Some rail guns use a plasma armature. In this set-up a thin metal foil is placed on the back of a non-conducting projectile. When power flows through this foil it vaporizes and becomes a plasma, which carries the current.

Here's how the pieces work together:

An electric current runs from the positive terminal of the power supply, up the positive rail, across the armature, and down the negative rail back to the power supply.

Current flowing in any wire creates a magnetic field around it -- a region where a magnetic force is felt. This force has both a magnitude and a direction. In a rail gun, the two rails act like wires, with a magnetic field circulating around each rail. The force lines of the magnetic field run in a counterclockwise circle around the positive rail and in a clockwise circle around the negative rail. The net magnetic field between the rails is directed vertically.

Like a charged wire in an electric field, the projectile experiences a force known as the Lorentz force (after the Dutch physicist Hendrik A. Lorentz). The Lorentz force is directed perpendicularly to the magnetic field and to the direction of the current flowing across the armature. You can see how this works in the diagram below.

Notice that the Lorentz force is parallel to the rails, acting away from the power supply. The magnitude of the force is determined by the equation F = (i)(L)(B), where F is the net force, i is the current, L is the length of the rails and B is the magnetic field. The force can be boosted by increasing either the length of the rails or the amount of current.

Because long rails pose design challenges, most rail guns use strong currents -- on the order of a million amps -- to generate tremendous force. The projectile, under the influence of the Lorentz force, accelerates to the end of the rails opposite the power supply and exits through an aperture. The circuit is broken, which ends the flow of current.

In theory, rail guns are the perfect solution for short- and long-range firepower. In reality, they present several serious problems:

Rail guns are of particular interest to the military, as an alternative to current large artillery. Rail gun ammunition, in the form of small tungsten missiles, would be relatively light, easy to transport and easy to handle. And because of their high velocities, rail gun missiles would be less susceptible to bullet drop and wind shift than current artillery shells. Course correction would be important, but all missiles fired from rail gun artillery would be guided by satellite.

It would be more difficult to engineer small arm rail guns, mainly because of recoil. Recoil, the backward action of a firearm upon discharge, is determined by the momentum of the escaping projectile. Multiplying a projectile's mass by its velocity yields its momentum, which for high-velocity rail gun projectiles would be considerable. A portable rail gun that fires very small bullets may be the solution. A small bullet would limit recoil but still carry enough kinetic energy to inflict serious damage.

Rail guns have also been proposed as important components of the Strategic Defense Initiative, popularly known as Star Wars. Star Wars is a U.S. government program responsible for the research and development of a space-based system to defend the nation from attack by strategic ballistic missiles. Rail guns could fire projectiles to intercept the incoming missiles. Some scientists argue that rail guns could also protect Earth from rogue asteroids, by firing high-velocity projectiles from orbit. Upon impact, the projectiles would either destroy the incoming asteroid or change its trajectory.

Rail guns have some interesting non-military applications as well. For one thing, they could potentially launch satellites or space shuttles into the upper atmosphere, where auxiliary rockets would kick in. On bodies without an atmosphere, such as the moon, rail guns could deliver projectiles to space without chemical propellant, which requires air to function.

Rail guns could also be used to initiate fusion reactions. Fusion occurs when two small atomic nuclei combine together to form a larger nucleus, a process that releases large amounts of energy. Atomic nuclei must be traveling at enormous velocities for this to happen. On the earth, some scientists propose using rail guns to fire pellets of fusible material at each other. The impact of the high-velocity pellets would create immense temperatures and pressures, enabling fusion to occur.

Many of these applications remain in the realm of theory, experimentation and development. Current rail guns do not generate sufficient energies to enable nuclear fusion to occur, for example. And it will likely be 2015 before an all-electric battleship uses a rail gun to launch projectiles at an enemy.

Still, the technology is promising. In 2003, the British Ministry of Defense hosted a one-eighth-scale test of an electromagnetic rail gun that achieved a muzzle velocity of Mach 6, or approximately 2,040 meters per second.

With continued successes such as these, the rail gun may one day be the weapon of choice on the battlefield and the propellant of choice on the launch pad.
