How Motion-powered Electronics Work

kinetic energy
Will innovative technology make it possible for this runner to power her MP3 player with her own movements? See more green science pictures.
Matthew Leete/Photodisc/Getty Images

As a 21st century human, you probably have quite an intimate relationship with electronic gadgets. From toothbrushes to iPhones, we fill our lives with a seemingly unending string of gizmos -- all of which depend on electricity to give us the tunes, data and vibrations we need to make it through the day.

Naturally, this brings with it a rather fierce dependency on battery chargers, adapters and power packs. Gotta score that electricity somehow, right? But even in situations where electricity seems scarce, energy is plentiful. It courses through our world, there for the taking. So why, in an energy-rich environment, should we ever have to deal with a dead cell phone battery?

Advertisement

That's the basic idea behind the newest breed of motion-powered electronics. If waterwheels and windmills can transform naturally occurring motion into electricity, then why not capitalize on the motion of the human body? This concept has led to such conservation-minded schemes as using pedestrian footsteps to power streetlights or powering whole dance clubs with the rhythmic thrashing of its revelers.

If either of those large-scale ideas were even feasible, then surely a morning jog would be enough to power a personal music player, right? The prospect is especially attractive given the increasing demands for leaner and more responsible energy usage.

In this article, we'll look at the emerging technology of motion-powered electronics.

Advertisement

Capturing Wasted Motion Energy

M2E kinetic cell phone charger
This kinetic cell phone charger is just one of the motion powered electronic devises under development from M2E Power, Inc.
Image courtesy M2E Power,Inc.

So imagine a world where you never have to charge your cell phone or MP3 player. While the technology may sound near future, the principal it depends on is straight out the 19th century.

English chemist and physicist Michael Faraday put forth his law of induction in 1831, which outlined how moving a conductor through a magnetic field induces a current in the conductor proportional to the speed of movement. Faraday's law of induction underlies the functionality of the world's power plants. From coal-burning plants to nuclear facilities, the idea is to create enough kinetic energy (the extra energy produced by motion) to move the conductor through the magnetic field.

Advertisement

Various companies have applied this technology to common gadgetry. An emergency radio boasts a crank on the side, which you can turn to produce the minimal electricity necessary to power it. More recently, developers have tweaked this design to produce a stronger electric current without the need for active cranking. These include shake flashlights and power packs, which boast special coil assemblies inside a short tube. At each end of the tube is a repellent magnet and, in the middle of the tube, you have the all-important magnetic assembly.

Repelled by the magnets on either end, the magnetic assembly is forced to hang out in the middle -- until it's shaken. When that happens, it's forced to bounce back between the two repellent forces, generating an electric current as it passes back and forth through the coil assembly.

This leads to two kinds of motion-powered electronics: those that require the active application of kinetic energy, such as cranking, and those that require passive kinetic energy, such as the up-and-down movement produced by walking or jogging.

The downside, of course, is that passive kinetic energy varies greatly depending on what you're doing. Going for a vigorous run? Great, enjoy a fully charged cell phone. But unless your nights are full of sleep walking or night-terror-induced thrashing, then don't expect to charge your batteries while sleeping out under the stars. Developers M2E Power (Motion to Energy) claim that, in tests, their batteries can turn six hours of average human movement into 30 to 60 minutes of cell phone power [source: LaMonica]

Advertisement

Putting Motion Power to Work

special forces
Night vision goggles are just one piece of military gadgetry that could benefit from motion-charged batteries.
Warrick Page/Getty Images News/Getty Images

Emerging motion-powered electronics technology has numerous applications, the most obvious being the creation of battery packs that keep your personal gadgetry going when you're on the move. Think of anytime you've ever held an item in your hand with a dead battery in it, and you likely have a candidate in mind. Here are a few additional applications for the technology:

Military use: Take a good look at the modern Special Forces soldier and just imagine how much battery power it takes to keep all the soldier's gear running. Does the modern army travel on its stomach, or on an endless string of AC adapters? According to M2E Power, the U.S. Army alone depends on 500 mobile battery-dependent devises, requiring soldiers to schlep up to 20 pounds (9 kilograms) of batteries [source: M2E]. For this reason, the U.S. military is very interested in modern motion power technology for its use in night vision goggles, various communication devises and small, portable generators.

Advertisement

Vehicle use: If you've ever enjoyed a bumpy ride in a vehicle, then you know there's definitely some kinetic energy available for the taking. In an equipped vehicle, on-board motion-powered electronics would be able to power themselves independent of the car battery and engine. Designers hope to use the technology to augment existing hybrid vehicle designs by allowing the vehicles to turn kinetic energy back into electrical energy in the battery. As such, motion-powered electronics could lower the outside energy demands for the vehicle.

Wind, wave and waterpower: Motion-powered electronics could also help in the improvement of traditional wind and water turbines, as well as using the natural movements of the tide to jostle electric generators in the same way a morning run would.

Explore the links on the next page to learn more about batteries, electrical energy and green technology.
