How the Tornado Intercept Vehicle Works

By: Tracy V. Wilson  |
Natural Disasters Image Gallery The TIV, before the addition of a rotating turret to house the IMAX camera. See more pictures of natural disasters.
Photo courtesy George Kourounis
Key Takeaways
  • The Tornado Intercept Vehicle (TIV) is a modified Ford F450 designed for close-up tornado filming, armored with steel plating and equipped with a 360° rotating turret for an IMAX camera.
  • The TIV's transformation involved reinforcing its structure with steel for protection against tornadoes, including 1/4-inch (0.6-cm) steel plate floors, a skeleton of steel tubing and I-beams and double-layered steel doors.
  • Despite its heavy armor, the TIV can reach speeds of up to 90 miles (145 kilometers) per hour, allowing it to safely enter and film inside tornadoes.

Most people -- especially those living in the American Midwest -- know how to boost their chances of surviving a tornado. First, get into a basement or a storm cellar. If that's not possible, hide in an interior, windowless room, preferably under a mattress or blankets. Never stay in a car or a mobile home -- lying a ditch, while definitely uncomfortable in the middle of a severe storm, is a lot safer.

Some people ignore this advice and become tornado chasers, but even chasers generally stay about a mile away from a tornado -- close enough to see, but relatively out of danger. Anyone wanting a closer look, or to actually get a glimpse of the interior of a tornado, would need a heavy, armored vehicle that could withstand intense winds, debris and hail.

Advertisement

That's exactly what IMAX cinematographer Sean Casey has built with his Tornado Intercept Vehicle (TIV). The TIV is big, heavy and armor plated. With it, Casey hopes to record a direct hit with a tornado and survive.

Read on to learn more about the TIV's armor and instruments, as well as what happens when it encounters a tornado.

Advertisement

Tank-Like Tripod

The TIV uses a Ford F-450’s dashboard, steering and transmission.
Photo courtesy George Kourounis

The TIV is essentially a large, mobile, armored tripod for an IMAX camera. Its purpose is to allow filmmakers to record footage from very close to -- or even inside of -- a tornado.

The TIV was originally a Ford F450 pickup truck. Its transformation into the TIV took three months of 7-day-a-week work. After stripping it down to its engine and chassis, Casey created a new frame and body out of steel, which uses:

Advertisement

  • 1/4" steel plate floors
  • A skeleton of 1/4" steel tubing and I-beams
  • 1/8" steel plates welded to the skeleton

Tires need to be accessible, yet protected from debris, so a hinged 1/8" steel flap covers each wheel well. Each of the four doors features a double layer of 1/8" steel plate. When closed, the doors lock into place with heavy steel bolts.

The TIV's side windows are 1/2" Lexan resin, a very strong plastic. For better visibility, its windshield is a scratch-resistant tempered glass and Lexan laminate.

The TIV’s side windows.
Photo courtesy George Kourounis

Since the TIV's purpose is to provide a safe spot for filming, it has a special military-style turret to house the IMAX camera. The turret spins 360° on 3" steel bearings, allowing the crew to shoot footage in any direction. The TIV also has two hatches for smaller format cameras.

The completed TIV with rotating turret.
Photo courtesy Matt Crowther

Including its skeleton and frame, the TIV weighs almost 14,000 pounds. In spite of all this weight, it can reach up to 90 mph.

In the next section, we will look at the equipment inside the TIV.

Advertisement

Portable Weather Station

The TIV, after the addition of the IMAX camera turret, parked beside two Doppler on Wheels units.
Photo courtesy George Kourounis

Since it can survive very high winds and hail, the TIV provides a good opportunity to collect tornado data. Inside the TIV are a variety of meteorological instruments, including:

  • A blade anemometer, which measures wind speed and force in one dimension
  • A sonic anemometer, which also measures wind speed and force, but in three dimensions
  • Two global positioning system (GPS) units
  • Tools for measuring temperature, pressure and humidity

Another weather research tool, the Doppler on Wheels (DOW), also uses the same instruments in addition to a mobile Doppler radar. The DOW, however, must stay between two and eight miles away from a tornado. Since the TIV houses the same instruments as the DOW, scientists can combine their data to create a more complete picture of the life of a tornado.

Advertisement

Now, let's look at what happens when the TIV finds a tornado.

Advertisement

Chasing a Tornado

The Dimmitt Tornado, south of Dimmitt Texas. Photographed as part of project VORTEX.
Photo courtesy National Oceanic and Atmospheric Administration/Department of Commerce

What happens when the TIV chases a tornado? That depends on whether Casey and his team are working with other chasers or independently. The first step is always research. All storm chasers must determine where tornadoes are likely to form and which approach to the storm will give them the best view while keeping them out of the most dangerous parts of the storm.

Recently, Casey has worked with Dr. Joshua Werman of the Center for Severe Weather Research (CSWR). The CSWR uses the DOWs and other equipment to study tornadoes. Members of the CSWR team analyze data about the storm and help decide where to deploy the TIV [ref]. When working with the CSWR, the TIV collects data up to the edge of the debris cloud, not into the tornado itself.

Advertisement

However, Casey designed and built the TIV with the goal of getting footage of a tornado approaching and then hitting the IMAX camera. In order to do this, he positions the TIV in the path of a tornado in a low-lying area. Then, the team films the tornado from within the TIV turret. Casey designed the TIV to withstand 200 mph winds, which accounts for about 75 percent of the tornadoes that form in the United States. This, and careful attention to the progression of the storm, reduces the likelihood of damage or destruction.

Eventually, footage from the TIV's expeditions will appear in an IMAX film about tornadoes called "Tornado Alley."

For more information about the TIV, tornadoes and tornado chasing, check out the links on the next page.

Advertisement

Frequently Asked Questions

How does the TIV navigate safely near tornadoes?
The TIV relies on advanced meteorological equipment and GPS to track tornadoes, as well as communication with storm-chasing teams for real-time data on tornado paths and intensity for safe navigation.
What are the main scientific contributions of the TIV’s tornado research?
The high-resolution IMAX footage the TIV captures aids in the analysis of tornado structure and dynamics, which can improve prediction models and safety measures.
